Integrating WebSocket in Spring Boot
1. Add spring-websocket Dependency
<dependency>
<groupId>org.springframework</groupId>
<artifactId>spring-websocket</artifactId>
</dependency>
2. Enable WebSocket Support
/**
* Enable WebSocket support
*/
@Configuration
public class WebsocketConfig {
@Bean
public ServerEndpointExporter serverEndpointExporter() {
return new ServerEndpointExporter();
}
}
3. WebSocket Utility Class
/**
* WebSocket utility class
*/
@Slf4j
public class WebsocketUtil {
private WebsocketUtil() {
}
/**
* Server stores client session objects
* key:clientId value:session
*/
public static final Map<String, Session> WEBSOCKET_CLIENT_SESSION_MAP = Maps.newConcurrentMap();
/**
* Server sends message to all clients
*
* @param message
*/
public static void sendMessageToAllClient(String message) {
if (WEBSOCKET_CLIENT_SESSION_MAP.isEmpty()) {
log.info("Currently no connected clients, message push ignored.");
return;
}
WEBSOCKET_CLIENT_SESSION_MAP.forEach((sessionId, session) -> {
try {
session.getBasicRemote().sendText(message);
} catch (Exception e) {
log.error("Server failed to send message to client [{}].", sessionId, e);
}
});
}
}
4. WebSocket Server
/**
* WebSocket server
*/
@Slf4j
@Component
@ServerEndpoint("/websocket")
public class WebsocketServer {
private String sessionId;
/**
* WebSocket connection established
*
* @param session
* @throws IOException
*/
@OnOpen
public void onOpen(Session session) throws IOException {
this.sessionId = session.getId();
if (WebsocketUtil.WEBSOCKET_CLIENT_SESSION_MAP.containsKey(this.sessionId)) {
WebsocketUtil.WEBSOCKET_CLIENT_SESSION_MAP.remove(this.sessionId).close();
}
WebsocketUtil.WEBSOCKET_CLIENT_SESSION_MAP.put(this.sessionId, session);
log.info("Client [{}] established WebSocket connection.", this.sessionId);
}
/**
* Close socket connection
*
* @param session
*/
@OnClose
public void onClose(Session session) {
if (WebsocketUtil.WEBSOCKET_CLIENT_SESSION_MAP.containsKey(session.getId())) {
WebsocketUtil.WEBSOCKET_CLIENT_SESSION_MAP.remove(session.getId());
log.info("Client [{}] disconnected WebSocket connection.", session.getId());
}
}
/**
* Message received
*
* @param message
*/
@OnMessage
public void OnMessage(String message) {
log.info("Received message from client {}: [{}].", this.sessionId, message);
}
/**
* Connection error
*
* @param session
* @param error
*/
@OnError
public void OnError(Session session, Throwable error) {
log.error("WebSocket connection error,", error);
}
}
5. Testing
Recommended Chrome plugin: Simple Web Socket Client
